Re: The1's Daily Daily Barina XC
carprog reads and writes the security section of the barina ecus.
kess writes the maps. you can go from 2.1 to 2.5 and back.
kess writes the maps. you can go from 2.1 to 2.5 and back.
Re: The1's Daily Daily Barina XC
yeh that's it, i think the barina ones are ME7 and VZ ME9.
-
- Posts: 159
- Joined: Fri Aug 25, 2017 5:28 pm
- cars: liberty gen 5
- Location: Adelaide
Re: The1's Daily Daily Barina XC
Hmm i wonder if i can go from a TS into a QD computer.
I tried to put a QD one in a TS car. Starts and runs fine but ended up having a couple of codes that weren't there before. I'm assuming the software is just different. TIS wont allow it but MPPS probably will.
I'll try it out. The TS one cost me a small fortune just to get out of trouble but I haven't used it yet so I might see if it works. Got 2 x QD's in the car.
I tried to put a QD one in a TS car. Starts and runs fine but ended up having a couple of codes that weren't there before. I'm assuming the software is just different. TIS wont allow it but MPPS probably will.
I'll try it out. The TS one cost me a small fortune just to get out of trouble but I haven't used it yet so I might see if it works. Got 2 x QD's in the car.
Re: The1's Daily Daily Barina XC
i havn't done a swap yet on my barina, the other ecu's i have here i dont know the immo code for yet.
-
- Posts: 159
- Joined: Fri Aug 25, 2017 5:28 pm
- cars: liberty gen 5
- Location: Adelaide
Re: The1's Daily Daily Barina XC
FVDI reads and resets the immo code without the rest of the car
Re: The1's Daily Daily Barina XC
immo from ecu? most pull immo code from cluster.
-
- Posts: 159
- Joined: Fri Aug 25, 2017 5:28 pm
- cars: liberty gen 5
- Location: Adelaide
Re: The1's Daily Daily Barina XC
id be interested to see where it's reading it from and what mode it's using, have you got something to log it doing the request?
Mode 23 reading flash doesn't get anything, ive gone through all the 21 and 1A PID requests and found nothing so it must be reading it via another mode or getting it from ram.
Mode 23 reading flash doesn't get anything, ive gone through all the 21 and 1A PID requests and found nothing so it must be reading it via another mode or getting it from ram.
-
- Posts: 159
- Joined: Fri Aug 25, 2017 5:28 pm
- cars: liberty gen 5
- Location: Adelaide
Re: The1's Daily Daily Barina XC
nah thats a bit out of my depth. if you explain to me how to do it i'll give it a go.
Re: The1's Daily Daily Barina XC
you'l need a splitter cable so you can connect 2 devices to the bus at the same time.
The other device needs to support kline KWP2000 for this ECU and software that can monitor the bus, for kline i use the passthru logger program with my vcxnano cable.
The other device needs to support kline KWP2000 for this ECU and software that can monitor the bus, for kline i use the passthru logger program with my vcxnano cable.
