VT V8 CFZC($A6C) Injector crank tables

[Wade]

Looks like there may be another 2 or 3 tables there but I’m not sure what they are.

[Wade]

The larger map is injector rate constant vs mg/cyl vs rpm. So you can see there’s still a couple tables in there, but I don’t think there’s as many as the v6’s have?

[Wade]

Vs v6 for comparison

[Wade]

4581 17x1 might be fuel pulse width multiplier vs ref pulses table a. Then 4592 I dare say is table b

[VX L67 Getrag]

Looks like I’ve got some work to do… so much easier if you have something similar look from but 11p being map is completely different & v6 stuff doesn’t seem to be even close!
The vs v8 mag stuff doesn’t have it defined either!

[Wade]

The offset would be 1 over from what I just posted I think

[Wade]

Enhanced vs v8 stuff looks to be at. Crank table scaler for max crank pulse width 4534. Crank fuel pw vs coolant 4549. Hopefully that helps with the vs v8

[VX L67 Getrag]

I dont think its right as the crank table b doesnt look right but it's getting close I think?

VT_V8_$A6C_Enhanced_v0.91b(add dtc's & crank fuel).xdf

(359.41 KiB) Downloaded 136 times

[Wade]

Yeah I’m not sure what the tables in-between are? Vs and vt v8 look the same in that area though. Might have to have a deeper look into the v8 stuff

[Wade]

i changed some of those tables address, should look better now. open loop afr didnt look right either, so changed that and then quickly went through looking for other tables.
